Fiber Laser Marker With Fiber Laser machine Environmental
Protection JHX-200200G
DESCRIPTION
CNC desktop fiber color laser marking writing machine for
eyeglasses
Fiber laser marking machine adopts most advanced fiber laser source
and high-quality galvo scanning system. It can provide stable power
output, perfect optical mode, good beam quality and high marking
speed.
Perfectly mark on metal, high hard alloy, oxide, electroplating,
coating, ABS, epoxy, ink, plastics
Features
1. No consumable, no pollution, energy saving and environmental
protection, in line with European environmental standards.
2. High precision marking, speed, depth of the engraving control
randomly.
3. Laser direct etching for burning, permanent marking, can not be
erased, not deformation loss, realize product traceability
requirements.
4. Support automatic code, serial number, batch number, date,
two-dimensional bar code and code marking.
5. The software uses the WINDOWS interface, compatible with
CORELDRAW, AUTOCAD, PHOTOSHOP and other software output file.
6. Support PLT, PCX, DXF, BMP and other documents, can direct use
of SHX, TTF font, support automatic code, serial number, batch
number, date, two-dimensional bar code and code marking, software
with graphic anti marking function.
7. Equipped with red light preview indication area function.
8. The foot switch control marking,automatic detection line
marking.
9. Beautifully marked effect,can enhance the grade of products,
improve the added value of products.
Material & Application
Applicable Materials of logo printing fiber
Applies to metal materials, stainless steel, copper, brass,
plastic, electroplating materials, coating materials, spraying
materials, rubber, resin, ceramic and so on.
ApplicableProducts of logo printing fiber
The device is widely used in electronic components, communications
equipment, automobile and motorcycle parts, instrumentation,
military products, mechanical hardware, measuring and tools, etc
Technical Specification
| Model | JHX-200200 |
| Laser Type | Import metal encapsulating rf Co2 laser tube |
| Laser Power | 40W/70W/100W/150W/250W/350W/500W |
| Marking Area | 200×200mm |
| Marking depth | ≦5mm |
| Cooling | Water Cooling |
| Marking speed | 0-120000mm/min |
| Marking repeat precision | ≦±0.01mm |
| Marking line width | ≦±0.01mm |
| Min character | 0.30mm |
| Pulse frequency | ≦100KHZ |
