Portable Fiber Laser Marker For Metal Laser Engraving Equipment
JHX-200200G
Fiber Laser Marking Machine DESCRIPTION
CNC desktop fiber color laser marking writing machine for
eyeglasses
Fiber laser marking machine adopts most advanced fiber laser source
and high-quality galvo scanning system. It can provide stable power
output, perfect optical mode, good beam quality and high marking
speed.
Perfectly mark on metal, high hard alloy, oxide, electroplating,
coating, ABS, epoxy, ink, plastics
Fiber Laser Marking Machine Features
Compact: The high-tech product, which is combined of laser device,
computer, auto controller and precision machinery.
High Precision: Re-position precision is 0.002mm
High Speed: Imported scanning system makes the scanning speed is up
to 7m/s
Easily Operating:Afford the specific coding software based on
Windows, You can input and output by computer according to edit in
the both of the specific coding software and
the graphic software such as AutoCAD, CorelDRAW and Photoshop.
Low Running Cost: No wearing part. Free maintaining.
1. High quality laser beam for fine marking, the minimum fine width
of laser can reach to 0.15mm.
2. High marking precision and speed.
3. Low consumption, energy saving, about 0.5KW for whole machine.
4. Light weight and small dimension.
5. 1 years warranty, during warranty period, we’ll send free new
part for replacement.
Material & Application
Applicable Materials of logo printing fiber
Applies to metal materials, stainless steel, copper, brass,
plastic, electroplating materials, coating materials, spraying
materials, rubber, resin, ceramic and so on.
ApplicableProducts of logo printing fiber
The device is widely used in electronic components, communications
equipment, automobile and motorcycle parts, instrumentation,
military products, mechanical hardware, measuring and tools, etc
Technical specification
| Product model | JHX-200200G |
| Laser Type | Fiber Laser |
| Laser Power | Option: 20W/30W |
| Working Area(mm) | 200x200 |
| Marking Area(mm) | ≦5 |
| Cooling | Air-cooling |
| Marking speed | 0-120000mm/min |
| Marking Repeat Precision | ≤±0.01mm |
| Marking line width | ±0.01mm |
| Min character | 0.30mm |
| Auxiliaries | Wind pump, Wind pipe etc |
| Pulse Frequency | ≤100KHZ |
| Working voltage | 220v±10%, 50-60HZ |
APPLICATION VIDEO
COLLOCATION
Fiber Laser marking machine with CNC desktop fiber color
