Galvo Laser for Denim Processing Jeans washing whisker laser
Machine JHX-3030
DESCRIPTION
Galvo Laser Systems use high powered lasers to vaporize material in
the laser beam path; eliminating hand labor and other complicated
extraction methods needed for small part scrap removal. Galvo Laser
Systems use mirror angles to reposition the laser beam in different
directions; making the process relatively quick. CO2 laser marking
machine adopts America CO2 RF laser generator and high speed galvo
scanner system.With high quality optic devices, high stability
laser generator,full automatic control system.The machine system
working with high precision and fast speed, very stable
performance, can work continuously for a long time and can be
applied directly in large quantities of online processing lines.
Features
High speed scanning galvanometer, high-performance imported laser,
precision accurate, stable performance, quick speed, high precision
of elevating work platform, realize the long time stable and
reliable operation, simple operation, easy to use, legible.
Control software adopts Windows engineering interface, compatible
with Coreldraw, AutoCAD, Photoshop, and other graphical output file
format, such as PLT, PCX, DXF, BMP, etc. Also directly use SHX, TIF
word stock, through the computer random design graphics.
1.import metal RF CO2 laser tube to ensure that the faster speed
and higher stability Adopts originally American imported RF
metallic CO2 laser tube Or China RF metallic co2 laser tube.
2. High Speed Galvo Scanner
3.high-quality optical device the output of light more smoothly,
ensure the consistency of marking
4.Good quality lens to ensure the high quality of machining
precision and speed, achieve 24-hour continuous processing
stability;
5.fine control board the system is stable and reliable, friendly
man-machine dialogue interface, wysiwyg, easy to operate.
6.Red Dot Pointer Preview the location before marking.
7.optical encapsulation, free maintenance, flexible installation,
convenient installation
8. Rotary Marking optional
Material & Application
Leather, cloth, wood, paper, acylic, epoxide resin, polyester resin
and such non-metal materials.
All kinds of metal and alloy; Rubber porcelain film, stone,
silicon; epoxies resin and ABS etc non-metal.
Technical specification
| Product model | JHX-3030 |
| Laser Type | Hermetic and detached CO2 laser tube |
| Laser Power | Option: 100W/150W |
| Working Area(mm) | 300x300 |
| Marking Area(mm) | ≦5 |
| Cooling | Water-cooling |
| Marking speed | 0-120000mmmin |
| Marking Repeat Precision | ≤±0.01mm |
| Marking line width | ±0.01mm |
| Min character | 0.30mm |
| Auxiliaries | Wind pump, Wind pipe etc |
| Pulse Frequency | ≤100KHZ |
| Working voltage | 220v±10%, 50-60HZ |
APPLICATION VIDEO
COLLOCATION
Leather engraving for jeans ,leather bag,wooden,paper
